Binary Trees
by Nick Parlante
This article introduces the basic concepts of binary trees, and then works through a series of practice problems with
solution code in C/C++ and Java. Binary trees have an elegant recursive pointer structure, so they are a good way to
learn recursive pointer algorithms.
Contents
Section 1
. Binary Tree Structure -- a quick introduction to binary trees and the code that operates on them
Section 2
. Binary Tree Problems -- practice problems in increasing order of difficulty
Section 3
. C Solutions -- solution code to the problems for C and C++ programmers
Section 4
. Java versions -- how binary trees work in Java, with solution code
Stanford CS Education Library -- #110
This is article #110 in the Stanford CS Education Library. This and other free CS materials are available at the
library (
http://cslibrary.stanford.edu/
). That people seeking education should have the opportunity to find it.
This article may be used, reproduced, excerpted, or sold so long as this paragraph is clearly reproduced. Copyright
2000-2001, Nick Parlante, nick.parlante@cs.stanford.edu.
Related CSLibrary Articles
Linked List Problems (
http://cslibrary.stanford.edu/105/
) -- a large collection of linked list problems
using various pointer techniques (while this binary tree article concentrates on recursion)
Pointer and Memory (
http://cslibrary.stanford.edu/102/
) -- basic concepts of pointers and memory
The Great Tree-List Problem (
http://cslibrary.stanford.edu/109/
) -- a great pointer recursion problem
that uses both trees and lists
Section 1 -- Introduction To Binary Trees
A binary tree is made of nodes, where each node contains a "left" pointer, a "right" pointer, and a data element.
The "root" pointer points to the topmost node in the tree. The left and right pointers recursively point to smaller
"subtrees" on either side. A null pointer represents a binary tree with no elements -- the empty tree. The formal
recursive definition is: a
binary tree
is either empty (represented by a null pointer), or is made of a single node,
where the left and right pointers (recursive definition ahead) each point to a
binary tree
.
Binary Trees
Page: 2
http://cslibrary.stanford.edu/110/
BinaryTrees.html
A "binary search tree" (BST) or "ordered binary tree" is a type of binary tree where the nodes are arranged in order:
for each node, all elements in its left subtree are less-or-equal to the node (<=), and all the elements in its right
subtree are greater than the node (>). The tree shown above is a binary search tree -- the "root" node is a 5, and its
left subtree nodes (1, 3, 4) are <= 5, and its right subtree nodes (6, 9) are > 5. Recursively, each of the subtrees must
also obey the binary search tree constraint: in the (1, 3, 4) subtree, the 3 is the root, the 1 <= 3 and 4 > 3. Watch out
for the exact wording in the problems -- a "binary search tree" is different from a "binary tree".
The nodes at the bottom edge of the tree have empty subtrees and are called "leaf" nodes (1, 4, 6) while the others
are "internal" nodes (3, 5, 9).
Binary Search Tree Niche
Basically, binary search trees are fast at insert and lookup. The next section presents the code for these two
algorithms. On average, a binary search tree algorithm can locate a node in an N node tree in order lg(N) time (log
base 2). Therefore, binary search trees are good for "dictionary" problems where the code inserts and looks up
information indexed by some key. The lg(N) behavior is the average case -- it's possible for a particular tree to be
much slower depending on its shape.
Strategy
Some of the problems in this article use plain binary trees, and some use binary search trees. In any case, the
problems concentrate on the combination of pointers and recursion. (See the articles linked above for pointer articles
that do not emphasize recursion.)
For each problem, there are two things to understand...
The node/pointer structure that makes up the tree and the code that manipulates it
The algorithm, typically recursive, that iterates over the tree
When thinking about a binary tree problem, it's often a good idea to draw a few little trees to think about the
various cases.
Binary Trees
Page: 3
http://cslibrary.stanford.edu/110/
BinaryTrees.html
Typical Binary Tree Code in C/C++
As an introduction, we'll look at the code for the two most basic binary search tree operations -- lookup() and
insert(). The code here works for C or C++. Java programers can read the discussion here, and then look at the Java
versions in
Section 4
.
In C or C++, the binary tree is built with a node type like this...
struct node {
int data;
struct node* left;
struct node* right;
}
Lookup()
Given a binary search tree and a "target" value, search the tree to see if it contains the target. The basic pattern of
the lookup() code occurs in many recursive tree algorithms: deal with the base case where the tree is empty, deal
with the current node, and then use recursion to deal with the subtrees. If the tree is a binary search tree, there is
often some sort of less-than test on the node to decide if the recursion should go left or right.
/*
Given a binary tree, return true if a node
with the target data is found in the tree. Recurs
down the tree, chooses the left or right
branch by comparing the target to each node.
*/
static int lookup(struct node* node, int target) {
// 1. Base case == empty tree
// in that case, the target is not found so return false
if (node == NULL) {
return(false);
}
else {
// 2. see if found here
if (target == node->data) return(true);
else {
// 3. otherwise recur down the correct subtree
if (target < node->data) return(lookup(node->left, target));
else return(lookup(node->right, target));
}
}
}
The lookup() algorithm could be written as a while-loop that iterates down the tree. Our version uses recursion to
help prepare you for the problems below that require recursion.
Pointer Changing Code
There is a common problem with pointer intensive code: what if a function needs to change one of the pointer
parameters passed to it? For example, the insert() function below may want to change the root pointer. In C and
C++, one solution uses pointers-to-pointers (aka "reference parameters"). That's a fine technique, but here we will
use the simpler technique that a function that wishes to change a pointer passed to it will
return
the new value of
the pointer to the caller. The caller is responsible for using the new value. Suppose we have a change() function
Binary Trees
Page: 4
http://cslibrary.stanford.edu/110/
BinaryTrees.html
that may change the the root, then a call to change() will look like this...
// suppose the variable "root" points to the tree
root = change(root);
We take the value returned by change(), and use it as the new value for root. This construct is a little awkward, but
it avoids using reference parameters which confuse some C and C++ programmers, and Java does not have reference
parameters at all. This allows us to focus on the recursion instead of the pointer mechanics. (For lots of problems
that use reference parameters, see CSLibrary #105, Linked List Problems,
http://cslibrary.stanford.edu/105/
).
Insert()
Insert() -- given a binary search tree and a number, insert a new node with the given number into the tree in the
correct place. The insert() code is similar to lookup(), but with the complication that it modifies the tree structure.
As described above, insert() returns the new tree pointer to use to its caller. Calling insert() with the number 5 on
this tree...
2
/ \
1 10
returns the tree...
2
/ \
1 10
/
5
The solution shown here introduces a newNode() helper function that builds a single node. The base-case/recursion
structure is similar to the structure in lookup() -- each call checks for the NULL case, looks at the node at hand, and
then recurs down the left or right subtree if needed.
/*
Helper function that allocates a new node
with the given data and NULL left and right
pointers.
*/
struct node* NewNode(int data) {
struct node* node = new(struct node); // "new" is like "malloc"
node->data = data;
node->left = NULL;
node->right = NULL;
return(node);
}
/*
Give a binary search tree and a number, inserts a new node
with the given number in the correct place in the tree.
Returns the new root pointer which the caller should
then use (the standard trick to avoid using reference
parameters).
*/
struct node* insert(struct node* node, int data) {
Binary Trees
Page: 5
http://cslibrary.stanford.edu/110/
BinaryTrees.html
// 1. If the tree is empty, return a new, single node
if (node == NULL) {
return(newNode(data));
}
else {
// 2. Otherwise, recur down the tree
if (data <= node->data) node->left = insert(node->left, data);
else node->right = insert(node->right, data);
return(node); // return the (unchanged) node pointer
}
}
The shape of a binary tree depends very much on the order that the nodes are inserted. In particular, if the nodes
are inserted in increasing order (1, 2, 3, 4), the tree nodes just grow to the right leading to a linked list shape where
all the left pointers are NULL. A similar thing happens if the nodes are inserted in decreasing order (4, 3, 2, 1). The
linked list shape defeats the lg(N) performance. We will not address that issue here, instead focusing on pointers
and recursion.
Section 2 -- Binary Tree Problems
Here are 14 binary tree problems in increasing order of difficulty. Some of the problems operate on binary search
trees (aka "ordered binary trees") while others work on plain binary trees with no special ordering. The next
section,
Section 3,
shows the solution code in C/C++.
Section 4
gives the background and solution code in Java. The
basic structure and recursion of the solution code is the same in both languages -- the differences are superficial.
Reading about a data structure is a fine introduction, but at some point the only way to learn is to actually try to
solve some problems starting with a blank sheet of paper. To get the most out of these problems, you should at least
attempt to solve them before looking at the solution. Even if your solution is not quite right, you will be building up
the right skills. With any pointer-based code, it's a good idea to make memory drawings of a a few simple cases to
see how the algorithm should work.
1. build123()
This is a very basic problem with a little pointer manipulation. (You can skip this problem if you are already
comfortable with pointers.) Write code that builds the following little 1-2-3 binary search tree...
2
/ \
1 3
Write the code in three different ways...
a: by calling newNode() three times, and using three pointer variables
b: by calling newNode() three times, and using only one pointer variable
c: by calling insert() three times passing it the root pointer to build up the tree
(In Java, write a build123() method that operates on the receiver to change it to be the 1-2-3 tree with the given
coding constraints. See
Section 4
.)
struct node* build123() {
